The ASV PT-30 is a Posi-Track loader manufactured by ASV. The PT30 loader features a 33.7 hp Perkins 403C-15 engine that gives it the power and reliability that you would expect from an ASV product. The ASV PT 30 features a radial lift design and has an operating weight of 3,305 lbs. A tipping load of 1,600 lbs gives it an operating capacity of 800 lbs at 50%. These machines feature a single-speed transmission with a ground speed up to 6 mph. The Posi-Track undercarriage features an 11 inch wide rubber track allowing the PT 30 a ground pressure of just 2.8 psi. The PT-30 offers more ground clearance (10 inches) than most other track loaders in its class. The PT30 also has a greater departure angle (55° degrees) that enables the units to push up on higher grades without bottoming out. This ASV has a low flow auxiliary hydraulic system that produces 10 gpm @ 3,000 psi.
