PT100 ForestryReturn To Diagram
The Terex PT-100 Forestry is a white ASV Posi-Track loader produced under the brand name Terex. The PT100 Forestry loader features a 99.9 hp Perkins 1104C-44T engine that gives it the power and reliability that you would expect from an Terex product. The Terex PT 100 Forestry features a radial lift design and has an operating weight of 11,425 lbs. A tipping load of 7,600 lbs gives it an operating capacity of 3,800 lbs at 50%. These machines feature a 2-speed transmission with a ground speed up to 6 mph in low speed and 11.5 mph in high range. The Posi-Track undercarriage features an 18 inch wide rubber track allowing the PT 100 Forestry a ground pressure of just 4.37 psi. The PT-100 Forestry offers more ground clearance (15 inches) than most other track loaders in its class. The PT100 Forestry also has a greater departure angle (40° degrees) that enables the units to push up on higher grades without bottoming out. This Terex has a low flow auxiliary hydraulic system that produces 20 gpm @ 3,650 psi and a high flow option of 38 gpm @ 3,650 psi.
